Sheet metal cutting industry applications
Scheme Parameters
| Scheme Components | Technical Parameters |
|---|---|
| Tray Rack ： |
Technical Parameters
|
| Stacker Crane: |
Double-column single-deep stacker crane, height 6.5m, Q=2300kg, SEW reduction motor, LHD fork Siemens series PLC |
| Conveyor System: | Combination of mobile carts, electric gantry robots, etc. |
| MWS/WCS/RF: | Warehouse Management System, Warehouse Control System, Handheld Barcode Scanner System |
| On-site Electronic Kanban: | LCD screen |
| Interface System: | Interface with ERP/MES |
Project Overview
The automated high-bay warehouse mainly consists of stacker crane system, storage rack system, pallets, mobile carts, electric gantry robots, electrical control system, barcode printing, scheduling system, warehouse management system, kanban system, RFS system and interface system, etc.
This project comprehensively solves the automation and information management of warehousing, storage, outbound, and surplus material return of metal sheets. It enables the automation of storage, transportation, and accounting.
Scheme Advantages
Realize rack storage of heavy-duty sheet metal.
Automatic docking between the high-bay warehouse and processing machines is achieved through mobile carts.
Automatic loading and unloading of sheet metal is achieved through electric gantry robots.
